Glass Nutsche Filters

Glass Nutsche Filters

We can supply Non-Jacketed Nutsche Filters up to 100 Liters, meant for Solid/Liquid separation @ kilo and lab scale. The design pressure is ATM /full vacuum.

The two main parts of the Nutsche Filter system are:

Bottom PTFE plate with filtrate chamber

PTFE head / glass top cover with manual operating stirrer. Motorised stirrer possible on demand.

The system is mounted on wheels, so that it can be moved comfortably to different locations. The filtrate chamber can be easily detachable which enables quick product collection. The liquid phase will be sucked through the filter into a receiver by using vacuum during filtration. The filter cake can be closed by lowering flat blades. After finishing the filtration process a washing step with simultaneous agitation may be carried out. The filter cake can be comfortably removed out of the filter chamber.

The key features of the Nutsche Filter are:-

Effective Filtration – Maximized filtering efficiency due to large filtration surface area.

Leak-proof Mounting System – Unique Filter Housing Prevents Leakage.

Easy Adjustment and Centering - Engineered Guided Mounting System for ease of Use.

Convenient Handling Cart. Mobile can be moved comfortably to different locations.

Nozzle Orientation – can be arranged to suit client’s needs. E.g Stirrer handle, Feed pipe, Spray nozzle.

Filter housing – Leak-proof mounting system, high sealing performance.

Filter : PEEK, PTFE,PP. Mesh Size: 1- 5,100µm.

Stirring apparatus – Locking, multi-directional stirring device maintains a uniform cake (upto 150mm).

Customized configuration are also available.

Easy cleaning.

Quick product collection

Transparency, since made of glass.

No metal in contact with product

Can apply the vacuum from the bottom to speed up the filtration.

Nutsch Filter capacities

Cap Nominal diameter

Filter area

m2

Maximum filling volume

( L)

Operating pressure

Operating Temperature
5L DN 200



0.023 5L FV / ATM (-)30 to (+) 170 deg c
10L DN 250



0.042 10L FV / ATM (-) 30 to (+) 170 deg c
20L DN 300



0.060 20L FV / ATM (-) 30 to (+) 170 deg c
50L DN 400



0.110 50L FV / ATM (-) 30 to (+) 170 deg C
100L

DN 500 0.170 100L FV / ATM (-) 30 to (+) 170 deg C
